Front loading machine for time, water and energy savings.

Back to Products

These front loading washing machines are upgraded models of horizontal washing machines. The loading and unloading is very easy in these modern design washing machines. The clothes are rotated and tumbled in both directions with the use of Reverse Forward timer to give perfect wash quality.

Download
Brochure

Technical Specifications

Model         Units            PWM-30F PWM-60F
Max Capacity    (Dry weight) kg. (lbs) 30 (66) 30(66)
Basket Diameter mm(in.) 813(32) 1016 (40)
Basket Depth mm(in.) 560 (22) 770 (30)
Basket Volume cu.m(cu.ft) 0.28 (10.2) 0.617 (21.8)
Water Inlet mm(in.) 25 (1) 38(1.5)
Steam Inlet mm(in.) 13 (0.5) 13 (0.5)
Drain Pipe mm(in.) 75 (3) 75 (3)
Cage Motor Kw(HP) 1.1 (1.5) 2.2 (3)
Machine Height mm(in.) 1676(66) (1900)75
Machine Depth mm(in.) 1300(51) 1500(59)
Machine Width mm(in.) 1200 (47) (1350)53

Standard Features


  • Fabricated with 304/316 Grade stainless steel using argon welding (TIG welding).
  • Precision Temperature controller.
  • Reverse/Forward Auto Timed.
  • Dosing system for Soaps and chemicals.

Optional Features


  • HMI with Touch screen controls
  • Customised Washing, Rinsing, Speed and dosing.
  • Inbuild water reusing feature by adding external tank.
  • Variable Water level Controller according to load.
