Closed loop Dry cleaning machine with more than 90% solvent recovery.

Back to Products

These machines uses transparent, non-flammable chemical named 'Perchloroethylene' to Dry clean clothes. This closed loop dry cleaning machine gives first class results when combined with additives like detergents, stain repellants, softners and odour absorbers. The inbuild distillation unit and oil recovery unit makes this machine safer for operators and the environment. Read More

Download
Brochure

Technical Specifications

Model Units PPA-10 PPA-15 PPA-22 PPA-30
Max Capacity    (Dry weight) kg.(lbs) 10 (22) 15(33) 22(48) 30(66)
Cage Diameter mm(in.) 813(32) 813(32) 1016 (40) 1016 (40)
Cage Depth mm(in.) 400(16) 560 (22) 560 (22) 770 (30)
Cage Volume cu.m(cu.ft) 0.21 (7.42) 0.28 (10.2) 0.453 (16) 0.617 (21.8)
Washing Speed RPM 30-35
Extract Speed RPM 400-550
Max G Force 138 138 172 172
Operating Load (Steam/Electric) KW 8/14 9/15 12/18 12/18

Machine Height mm(in.) 2082 (82) 2286 (90) 2286 (90) 2286 (90)
Machine Depth mm(in.) 1423 (56) 1423 (56) 1500(59) 1700(67)
Machine Width mm(in.) 1828 (72) 1828 (72) 2133(84) 2133(84)
Blower Motor Kw(hp) 1.5 (2) 1.5 (2) 1.5 (2) 1.5 (2)
Cage Motor Kw(hp) 2.2 (3) 3.7 (5) 5.2(7) 5.2(7)
Solvent Pump Kw(hp) 0.75 (1) 0.75 (1) 1.1(1.5) 1.1(1.5)
Compressor  Kw 3.5 3.5 4 4
Air Heater Kw 6 6 6 6
Distillation Heaters Kw 9 9 12 12
Operating Volts/Hz   400/50

Standard Features


  • 2 self cleaning SS solvent tanks.
  • Latest Touch screen HMI with fault detection controls
  • User defined program storage with Transferrable Recipes
  • Aerodynamic Recovery section
  • Solvent Recovery via Refrigeration Technology
  • Self Cleaning emission free still
  • Cage overflow preventor.
  • Still Overflow preventor
  • Soap Dosing unit

Optional Features


  • Steam heating or Electric Heating.
  • Default color is white (can be changed acc. to requirement).
